Description
PRODUCT PROPERTIES
- Operation Operation without power supply
- Micro-switch separated from the process
- All wetted parts stainless steel
- Side or top mounting
- Fixed or adjustable switch differential
- Submersible versions
- Various process connections
- Operational check via optional tester
- Flame-proof models
- SIL1 approval
APPLICATIONS
- Liquids with minimum 0.7 kg/dm3 density
- Fail-safe and control level switches in closed tanks
- Ballast tanks on ships
- Chemical industry
- Food and beverage
- Power plants
- Oil industry
- Water industry
| Ambient temperature: | – 20 °C … + 80 °C |
|---|---|
| Process temperature: | – 40 °C … + 250 °C |
| Pressure: | max. 25 bar |
| Output: | 250 V AC, 10 A NO/NC |
| Process connection: | flanges or 2″ thread |
| Protection: | IP65, IP68 |
| Approvals: | ATEX, IEC Ex, INMETRO, EAC, DNV GL (Marine), BV (Marine), SIL1 |
